GATE PULSAR D HPA Engine

Features

• Well thought-out design makes it easy to maintenance
• Smallest dual solenoid valve closed-bolt HPA engine with innovative cycle synchronization
• Innovative automatic synchronization of the nozzle movement cycle enables easier calibration no need to fire thousands of rounds to achieve good FPS results and stable BB trajectories
• Due to its innovative BB feed system and closed-bolt mode, it is definitely less sensitive to replica and assembly quality
• Razor-sharp accuracy of the system no unstable hop-up system symptom like in other HPA systems
• Compatible with AEG nozzles
• Zero nozzle wobble resulting in stable FPS when paired with GATE AEG nozzles, which translates into stable FPS and no mid-cap syndrome
• Eliminated mid-cap syndrome thanks to high dimensional tolerance
• FPS stability in full AUTO mode
• No FPS drops on AUTO relative to SEMI mode at high RPS up to 40 RPS with no FPS drops

PULSAR D HPA Engine (dual solenoid, closed-bolt) with TITAN II Bluetooth® EXPERT thanks to optical sensors combined with HPA technology, you get an absurd trigger response never before seen in airsoft. Get insane muzzle velocities ranging from 250-650 FPS & ROF from 1-40 RPS for CQB, assault, and sniper replicas. Closed-bolt and the innovative feed system guarantee you a straight and repeatable BB trajectory even in full AUTO every time. Engine calibration has never been easier PULSAR D & TITAN II Bluetooth® is introducing innovative cycle synchronization automation. The most advanced and user-friendly GCS app lets you access a multitude of settings and configurations like binary trigger, trigger sensitivity, ROF live via Bluetooth®. You can even use a remote trigger on your smartwatch. Install the world's smallest and most advanced dual solenoid valve HPA engine in replicas where previously not possible due to size constraints. Choose one of the five nozzles included or use a regular AEG one. Take your HPA replica into the future!

Manufacturer: GATE

Specifications:

Solenoid Voltage Range: 5-8.4V
Operating Pressure: 60-140 PSI high pressure only
Gas Consumption: For 90 PSI and a 48 ci/0.8 l 300 bar/4500 PSI bottle 0.7 PSI per shot
Dimensions w/ Cycle Sync Automation (Length x Diameter x Height): 102mm x 25.4mm x 38.5mm
Dimensions (Length x Diameter x Height): 100 mm x 25.4 mm x 32mm
Finished Product Weight: 90g
Operating Temperature Range: min. -15°C, max. +50°C
Relative Humidity: ≤80%
Adjustable ROF: 1 to 40 RPS
Velocity: 250 650 FPS
Operation Mode: Closed Bolt / Open Bolt
Pressure Range: 60 to 140 PSI
AEG Nozzle Compatibility:

20.50mm

20.80mm

21.15mm

21.25mm

21.40mm

Package Includes: Engine, 5x Nozzles

Note: This item does not come with a MOSFET. Engine Only.
