Features
- Ultra heavy duty steel alloy blend.
- Level III rifle protection and multi-hit capable
- FragLock base coating to deflect fragmentation
- Lasts a lot longer than polyethylene or ceramic alternatives
- Base coat seals the armor from perspiration
- Capable of protecting against several direct hits while still being less bulky than competing materials
- NIJ 0101.06 certified
- 20 Year shelf life
Affordable, strong, reliable: the Heritage Plate is made of a custom steel alloy blend that increases its strength. It boasts Level III rifle protection, multi-hit capability and a FragLock Base Coating to deflect fragmentation. Additionally, this armor plate has a lengthy shelf life, retaining its full strength for twenty years.
The armor plate comes in flat and curved forms. The Build-Up upgrade increases the thickness of the FragLock coat so as to capture virtually all fragmentation within the plate, ensuring it is a complete non-issue in the fight.
Essential protection ought to be affordable and reliable, which is why Armored Republic is proud to offer one of the most cost-effective plates on the market with our AR500 Armor® Heritage Plate: The plate material is a steel alloy blend, has our patented Advanced Shooters Cut shape and is covered with an exclusive FragLock Base Coat (build-up coating is available).
This steel plate lasts a lot longer than polyethylene or ceramic alternatives because of the FragLock coating's 20-year maintenance-free shelf life. While our base coat seals the armor from perspiration, our build-up coating prevents fragmentation injury.
Our AR500 Armor® Heritage armor plate, unlike ceramic or polyethylene alternatives, is capable of protecting against several direct hits while still being less bulky than competing materials. It also has been independently tested in accordance with NIJ 0101.06 threat levels through Oregon Ballistics (OBL) and H.P. White Laboratories. This means that its level 3 body armor protection is rated to stop 7.62x51 M80 NATO Ball (.308 Winchester) at a velocity of up to 2,750 FPS and special threat tested to stop 5.56mm M855/SS109 (Green Tip) at a velocity of 2,750 FPS.
Manufacturer: AR500 Armor
Specifications:
Size (mm/in): 254 x 304.8 / 10 x 12
Thickness (mm/in): 15.24 / 0.6
Weight (g/lb): 3855.53 / 8.5
Coat: Base
Protection: 7.62mm FMJ, steel-jacketed bullets (U.S. Military designation M80) with a specified mass of 9.6g (147gr) and a velocity of 2,750 ft/s (+/- 50 ft/s).
Capability: Edge-to-edge multi-hit protection
Form: Curved
Shelf Life: 20 Years
Plate Carrier Compatibility: Testudo, Valkyrie, Invictus
Material: AR500 Steel Alloy, FragLock Coating
Frequently Asked QuestionsWhat does level 3 body armor protect against? The National Institute of Justice (NIJ) protection rating for level 3 body armor is 6x shots of 7.62x51mm @ 2,780 FPS from 51' away. Some level III plates are considered special threat plates in that in addition to this they will address other common threats. For example, our level 3 Heritage Plate will stop 5.56x45 M855 green tips @ 2,750 FPS from a 16 barrel, while our P2 plates will stop 5.56x45 M193 Ball @ 3,200 FPS.What will IIIA body armor stop? IIIA body armor is rated to stop 6x hits from 125-grain .357 SIG FMJ flat-nose bullets with speeds up to 1,470 feet per second and 240-grain .44 Magnum Semi-Jacketed Hollow Point (SJHP) bullets with speeds up to 1,430 ft/s, along with all lesser handgun threats.Can civilians own level 3 body armor? Yes, except in New York and Connecticut. Both of these states restrict body armor ownership to law enforcement and active military only.About AR500 Armor
AR500 Armor® launched its own line of ballistic armor and body armor solutions in 2012. We entered the industry with the mindset of manufacturing top quality, reliable products that offered our customers high value solutions. Our products are intended for responsible law-abiding American citizens, our law-enforcement personnel, and our military personnel; we currently sell to legal residents of the United States.
With our unique in-house manufacturing processes and ability to acquire material made to our specifications, weve set the standard for ballistic steel core body armor. Utilizing industry leading spall and fragmentation mitigation coatings we've further increased what's possible with ballistic steel. Our products are available through our website and authorized dealers throughout the United States. AR500 Armor® is a privately held business; Our Headquarters, team members, and manufacturing facility are located in Phoenix, Arizona.
